1/2'' ultra flexible coxial cable line for telecommunication

Item	Material	Diameter(MM)
1. Inner Conductor	Naked copper or copper-clad aluminium conductor	3.6
2. Insulator	EPO	8.8
3. Outer Conductor	Threaded copper pipe	12.1
4. Sheath	PE or LSZH flame-retardant polyolefine cable	13.4

Electric Performance
Electric capacity(pF/m)	80
Electric resistance(ohm)	50
Transfer Rate(%)	83
DC inner conductor resistance(Ω/km)	2.85/1.78
DC outer conductor resistance(Ω/km)	3.5
Attenuation Shield(dB)	>120
Peak Power(KW)	19
Peak Voltage(KV)	1.13
Insulation Resistance(MΩ.km)	>5000
Cut off frequency(GHz)	12.5
Insulation voltage (KVrms)	2.5
Sheath Spark(KVrms)	5.0

Mechanical&Environmental Performance
Storage Temperature(℃)	-55 to +85
Installation Temperature(℃)	-20 to +60
Work Temperature(℃)	-55 to +85
Minimum bending radius(mm)	50
Min repeated bending radius(mm)	125
Tensile strength; (KG)	110
ROHS Eco Friendly	Yes

Attenuation and Mean Power (VSWR1.0,20℃)
Frequency(MHz)	Mean Power (KW)	Attenuation(dB/m)
100	3.03	3.22
200	2.11	4.65
450	1.37	7.20
800	1.00	9.86
900	0.94	10.56
1000	0.88	11.15
1500	0.70	13.80
1800	0.63	15.55
2000	0.59	16.40
2200	0.56	17.35
2400	0.53	18.10
2500	0.52	18.50
3000	0.48	20.90
